Features

Gold Fin

More resistant to corrosion

Warranty

5 Years (indoor and outdoor unit)

Great Performance

Air force up to a long distance

Self Cleaning

Keep internal side dry, prevent bacteria

Features

Great Performance

Air force up to a long distance

Gold Fin

More resistant to corrosion

Self Cleaning

Keep internal side dry, prevent bacteria

Warranty

5 Years (indoor and outdoor unit)

Features

Gold Fin

More resistant to corrosion

Great Performance

Air force up to a long distance

Self Cleaning

Keep internal side dry, prevent bacteria

Warranty

5 Years (indoor and outdoor unit)

Features

Self Cleaning

Keep internal side dry, prevent bacteria

Warranty

5 Years (indoor and outdoor unit)

Great Performance

Air force up to a long distance

Gold Fin

More resistant to corrosion

Rated Capacity, Cooling	32000 BTU
Rated Capacity, Heating	32000 BTU
Rated Running Current, Cooling	14.5 A
Rated Running Current, Heating	12.5 A
Max. Input Power	4000 W
Max. Input Current	19 A
EER Cooling	2.51 W/W
COP Heating	2.87 W/W
Power Supply Source	220~240V/50HZ
Refrigerant	R22
Refrigerant Charged	1950 g
Max. Discharge Pressure	3.4 Mpa
Max. Suction Pressure	0.8 Mpa
Air Flow Volume	1200 m3/h
Indoor Unit Noise Power	48 dB（A)
Outdoor Unit Noise Power	59 dB（A)
Indoor Unit Weight （Net)	42 Kg

Outdoor Unit Weight (Net)	54 Kg
Indoor Evaporator Bend	1
Indoor Evaporator Row	2
Indoor Evaporator Pipe Diameter	7*0.24 mm
Indoor Fan Motor	YDK68-8B
Indoor Net Dimension	1780×500×300 mm
Indoor Packing Dimension	1890690460 mm
Liquid Valve	Φ6.35*0.5 mm
Gas Valve	Φ15.88×0.75 mm
Outdoor Compressor Brand	GMCC
Outdoor Compressor Model	PH440
Outdoor Fan Motor	YDK69-6B
Outdoor Condenser Pipe Diameter	Φ7*0.24 mm
Outdoor Condenser Row	2
Outdoor Net Dimension	800×690×300 mm
Outdoor Packing Dimension	935415760 mm
Container Loading 40HC	78 Units

T3 Floor

GM-F36K DIGITAL

Rated Capacity, Cooling	36000 BTU
Rated Capacity, Geating	36000 BTU
Rated Running Current, Cooling	17 A
Rated Running Current, Geating	15.7 A
Max. Input Power	5100 W
Max. Input Current	27 A
EER Cooling	2.57 W/W
COP Heating	2.97 W/W
Power Supply Source	220~240V/50HZ
Refrigerant	R22
Refrigerant Charged	2700 g
Max. Discharge Pressure	2.8 Mpa
Max. Suction Pressure	0.8 Mpa
Air Flow Volume	1600 m3/h
Indoor Unit Noise Power	52 dB（A)
Outdoor Unit Noise Power	62 dB（A)
Indoor Unit Weight （Net)	50 Kg

Outdoor Unit Weight (Net)	65 Kg
Indoor Evaporator Bend	1
Indoor Evaporator Row	2
Indoor Evaporator Pipe Diameter	Φ9.52×0.27 mm
Indoor Fan Motor	YDK120-8B
Indoor Net Dimension	560×1910×360 mm
Indoor Packing Dimension	680×2020×510 mm
Liquid Valve	Φ9.52*0.6 mm
Gas Valve	Φ15.88×0.75 mm
Outdoor Compressor Brand	MITSUBISHI
Outdoor Compressor Model	LHT53VBAC
Outdoor Fan Motor	YDK85-6E
Outdoor Condenser Pipe Diameter	Φ9.52×0.27 mm
Outdoor Condenser Row	2
Outdoor Net Dimension	902×795×332 mm
Outdoor Packing Dimension	1030427865 mm
Container Loading 40HC	60 Units

T3 Floor

GM-F48K DIGITAL

Rated Capacity, Cooling	48000 BTU
Rated Capacity, Heating	48000 BTU
Rated Running Current, Cooling	8.56 A
Rated Running Current, Heating	8.56 A
Max. Input Power	7800 W
Max. Input Current	12.7 A
EER Cooling	2.59 W/W
COP Heating	2.84 W/W
Power Supply Source	380-415V~/3N~
Refrigerant	R22
Refrigerant Charged	3330 g
Max. Discharge Pressure	2.8 Mpa
Max. Suction Pressure	0.8 Mpa
Air Flow Volume	2000 m3/h
Indoor Unit Noise Power	52 dB（A)
Outdoor Unit Noise Power	62 dB（A)
Indoor Unit Weight （Net)	58 Kg

Outdoor Unit Weight (Net)	105 Kg
Indoor Evaporator Bend	2
Indoor Evaporator Row	2
Indoor Evaporator Pipe Diameter	Φ9.52×0.27 mm
Indoor Fan Motor	YDK120-8B
Indoor Net Dimension	560×1910×360 mm
Indoor Packing Dimension	680×2020×510 mm
Liquid Valve	Φ9.52*0.6 mm
Gas Valve	Φ19*0.75 mm
Outdoor Compressor Brand	SANYO
Outdoor Compressor Model	C-SB373
Outdoor Fan Motor	YDK70-6-358L
Outdoor Condenser Pipe Diameter	Φ9.52×0.27 mm
Outdoor Condenser Row	2
Outdoor Net Dimension	945×340×1255 mm
Outdoor Packing Dimension	11004321370 mm
Container Loading 40HC	46 Units

T3 Floor

GM-F60K DIGITAL

Rated Capacity, Cooling	60000 BTU
Rated Capacity, Heating	60000 BTU
Rated Running Current, Cooling	8.1 A
Rated Running Current, Heating	8.6 A
Max. Input Power	7800 W
Max. Input Current	12.7 A
EER Cooling	2.61 W/W
COP Heating	2.92 W/W
Power Supply Source	380-415V~/3N~
Refrigerant	R22
Refrigerant Charged	3900 g
Max. Discharge Pressure	2.8 Mpa
Max. Suction Pressure	0.8 Mpa
Air Flow Volume	1800 m3/h
Indoor Unit Noise Power	52 dB（A)
Outdoor Unit Noise Power	62 dB（A)
Indoor Unit Weight （Net)	58 Kg

Outdoor Unit Weight (Net)	110 Kg
Indoor Evaporator Bend	2
Indoor Evaporator Row	2
Indoor Evaporator Pipe Diameter	Φ9.52×0.27 mm
Indoor Fan Motor	YDK120-8B
Indoor Net Dimension	560×1910×360 mm
Indoor Packing Dimension	680×2020×510 mm
Liquid Valve	Φ9.52*0.6 mm
Gas Valve	Φ19*0.75 mm
Outdoor Compressor Brand	HIGHLY
Outdoor Compressor Model	TE800
Outdoor Fan Motor	YDK70-6-358L
Outdoor Condenser Pipe Diameter	Φ9.52×0.27 mm
Outdoor Condenser Row	2
Outdoor Net Dimension	1010×1260×340 mm
Outdoor Packing Dimension	1100×1370×430 mm
Container Loading 40HC	46 Units
